R&S®ETH 手持TV频谱分析仪
Model overviewFrequency range Model100 kHz to 3.6 GHz
R&S®ETH, model .14 100 kHz to 8.0 GHz R&S®ETH, model .18
深圳超利18320894501
R&S®ETH Handheld TV AnalyzerAt a glanceEasy-to-replace battery.The
R&S®ETH handheld TV analyzer is the compact combination of a
TV analyzer, spectrum analyzer and network analyzer. It supports the
digital DVB-T, DVB-H and ISDB-T TV standards. Its functional
展开剩余82%versatility eliminates the need for other measuring equipment.
The analyzer covers the frequency range up to 3.6 GHz or 8 GHz.
The housing was specially designed for portable use and is therefore
rugged and splash-proof. The large, daylight-friendly color display,
he low weight and the replaceable lithium-ion battery enhance the
analyzer's portability. To improve its receive sensitivity and selectivity,
the R&S®ETH can be equipped with internal preselection followed by a
preamplifier. The core component of the R&S®ETH is an FPGA-based realtime
digital TV demodulator that offers maximum measurement performance and
provides a demodulated MPEG-2 transport stream at the TS-ASI output. The
measurement results are displayed on straightforward measurement screens
and can be stored in the internal memory or on external storage media such
s SD card or USB memory stick. The R&S®ETHView Windows PC software,
which comes with the analyzer, allows easy documentation of measurement
results. R&S®ETHView enables the user to edit and redefine the channel tables,
measurement profiles, transducers and limit tables delivered with the instrument
and to load them in the R&S®ETH. The data is transferred via the USB or
LAN interface.Key facts❙ TV, spectrum and network analyzer in a single box ❙
Frequency range up to 3.6 GHz or 8 GHz ❙ High-precision demodulator (MER typ. 45 dB) ❙ Wide
input level range (–76 dBm to +10 dBm) for quasi-error-free transport stream decoding ❙
Compact, lightweight, portable instrument that runs max. 4.5 hours on batteryThe
R&S®ETH handheld TV analyzer was specially developed for coverage measurements as
well as for service and maintenance work on DVB-T, DVB-H and ISDB-T gap-filler and
low-power transmitters. The universal capabilities of the R&S®ETH also make it useful in t
he repair and development of
Comprehensive TV, spectrum and network analysis functionality❙ Measurement of all DVB-T, DVB-H and ISDB-T signal parameters ❙ Display of constellation diagram, channel impulse response, OFDM spectrum with shoulder distance and MER(k) ❙ Wide input level range due to integrated preselection and preampliff er ❙ Full-featured spectrum analyzer ❙ Network analysis and distance-to-fault measurement by means of integrated tracking generator ❙ Frequency locked to external reference ❙ High-precision power measurement with external Rohde & Schwarz power sensors ❙ Field-strength measurement using isotropic antenna
